Lined Ball Valve
Our PFA lined ball valves are designed for handling aggressive corrosive conditions, ensuring long-term durability under the harshest conditions. With exceptional corrosion resistance, these valves are used in industries like chemical processing, chlor-alkali, mining, petrochemicals, pulp and paper, steel, pharmaceuticals, and wastewater treatment. We also offer ball valves with FEP/PVDF/ETFE/ECTFE & PPH liners.
Our ball valves can operate in a wide temperature range (- 40°C to 200°C) and can withstand pressures up to 15 bar . Certified for CLASS VI – Tight Shutoff as per API 598, these valves have zero leakage ensuring safe and reliable operations.
Our ball valves come with versatile operational options—choose from a robust cast iron lever, handwheel, electric, or pneumatic actuator for effortless control. The PTFE seats ensure low-friction performance and high endurance, while our single-piece shaft and ball, uniformly lined with PFA, ensures corrosion free long-lasting service. Available in sizes from DN15 – DN 300 ( 1/2” to 12”), our valves are ready to meet the demands of your project.
With decades of industry expertise, our team is dedicated to delivering high-quality, cost-effective solutions tailored to your needs.
Technical Specifications
- Size Range: DN15-DN300 (1/2″-12”)
- Design: BS EN 17292 / ANSI B16.34
- Face to Face: EN 558-1 Series 7 / ANSI B 16.1
- Rating: ANSI B 16.5, #150 / DIN PN 16 / PN 10 / JIS
- Body Type: Reduced Port and Full Port , Center split or side split
- Sealing : CLASS VI, Tight SHUT OFF as per API 598
- Temperature: - 40 DEG.C to 200 DEG. C
- Trim insert : ASTM A 351 GR. CF8 or 8m / ASTM A 890 GR. 4A (CD3MN)
- Test standards: API 598, ISO 9393-2 or BS EN 12266-1-2003. (Hydro test, Pneumatic test, Spark test)
- Body Materials: ASTM A 216 GR. WCB / ASTM A 351 GR. CF 8 or 8M (SS316) / SS304 / ASTM A 890 GR. 4A (CD3MN) / Super Duplex / Alloy 20 / Hastelloy C
- Lining : PFA / FEP / PVDF / ETFE / ECTFE / PPH / Antistatic PFA
Product Features
Highly Corrosion-resistance PFA lining
Made from 100% virgin high purity Grade A PFA, with optional antistatic PFA for enhanced safety.
Single Piece Stem
and Disc
Single-piece stem and disc construction provides superior strength and prevents misalignment of stem and disc.
High Strength
Trim Insert
Stainless steel trim insert ensures high torsional strength, minimizing twisting to ensure leak free closure.
Investment casted
body
Made with investment castings, the metal housing ensures an intact and uniform lining.
Class VI Tight
shut off
Designed to API 598 standards for Class VI tight shutoff, ensuring zero leakage in all operating conditions.
Certified
Quality
Available with CE / PED certification and Hydro test, Pneumatic test, Spark test, Helium test according to API 598 / BS EN 12266-1
ISO mounting
Pad
Direct mount actuation pad provided for quick and easy automation.
Approved
ISO 15848-1
Fugitive Emission Certification
Documents
| Name | Download | |||
|---|---|---|---|---|
|
GreyTec -Lined Ball Valve – Brochure.pdf |
|
|
|
Case Stories
Header
Lorem Ipsum is simply dummy text of the printing and typesetting industry. Lorem Ipsum has been the industry’s standard dummy text ever since the 1500s, when an when an unknown printer took a galley of type and scrambled it to make a type specimen book.
Header
Lorem Ipsum is simply dummy text of the printing and typesetting industry. Lorem Ipsum has been the industry’s standard dummy text ever since the 1500s, when an when an unknown printer took a galley of type and scrambled it to make a type specimen book.
Related Products
FAQ's
A PFA-lined ball valve features a body lined with PFA (Perfluoroalkoxy alkanes) and a ball lined from PFA, providing excellent corrosion resistance and low permeability. This makes it ideal for handling aggressive chemicals, where standard valves may not be suitable.
PFA lining offers high chemical resistance, a smooth surface that minimizes friction and fouling. The PFA lining acts as a barrier between the flowing medium and the valve's internal components, effectively shielding them from corrosive substances.
Yes, these valves generally require minimal maintenance. Regular inspection for wear and tear, along with routine cleaning, can help ensure their longevity
Ball valves consist of a spherical ball with a bore that is rotated to open or close the valve. When aligned with the valve body, the bore allows fluid flow; when perpendicular, it seals the valve.
PFA lined ball valves have a specialized PFA liner on the inside of the valve and the trim insert, making them ideal for corrosive environments, where standard valves may not be suitable.
These valves offer quick opening, full bore operation, and low pressure drop, suitable for automated or manual use in shutoff, throttling, and flow control of of liquids, gases, and slurries, ensuring tight sealing and efficient operation.
Yes, these valves find extensive application in Chlor-Alkali industries handling aggressive chemicals like hydrochloric acid and caustic soda.
Certainly! We offer Antistatic PFA lined Valves in Dupont's grade C 980 or 3M Dyneon's 8502 ESDZ. Choosing the correct material is crucial, as a grounding spring alone cannot dissipate static charge in a standard PFA grade, which is non-conductive.
We keep many valves in stock in our warehouse in Netherlands, India and USA and can ship them within a week.
Our ball valves are available in numerous sizes DN15-DN300 (1/2"-12") providing a range of options to meet diverse industrial needs.
